Simplecom CM317 7-Port HDMI 2.0 Switch with Remote 7 IN 1 OUT Splitter HDCP 2.2 4K@60Hz

This 7-Port HDMI 2.0 switch allows you to connect multiple HDMI source devices to a single display port, simplifying your setup and eliminating the need to manually change cables. It supports high-quality video and audio transmission, making it suitable for various entertainment and presentation devices.

Features

• Supports HDMI 2.0 and is backward compatible with previous HDMI versions
• Connects up to seven HDMI source devices to one display port
• Auto switching feature detects and selects the active input automatically
• Manual control via button or remote control included
• Supports 4K resolution at 60Hz and 18Gbps bandwidth
• LED indicators show the active input source
• Plug and play, powered via USB for easy setup

Specifications

• Model: CM317
• HDMI version: HDMI 2.0b
• HDCP version: HDCP 2.2
• HDMI Inputs: 7x HDMI Female
• HDMI Output: 1x HDMI Male
• Maximum bandwidth: 18Gbps
• Supported resolutions: 4K, 1440p, 1080p, 720p, and others
• Maximum refresh rate: 4K@60Hz, 1080p@120Hz
• Supported color depths: 12bit, 14bit, 16bit, 36bit deep color, RGB 8:8:8
• HDR support: HDR 10, Dolby Vision
• Audio formats supported: DTS, DTS-HD, Dolby TrueHD, Dolby AC-3, PCM, LPCM
• Power input: DC 5V
• Operating temperature: 0??C to 70??C
• Dimensions: 19.5 x 7 x 2.3 cm
• Weight: 291g

Package Content

• 1x 7-Port HDMI Switch
• 1x Remote Control
• 1x 5V Power Adapter
• 1x USB Power Cable
