SIMPLECOM EC412 Dual M.2 (B Key and M Key) to PCI-E x4 and SATA 6G Expansion Card

This expansion card allows you to add NGFF M.2 devices such as SSDs to your existing PC motherboard. It features dual M.2 slots that support both PCI-E based NVMe SSDs and legacy SATA based SSDs, enabling you to connect two M.2 drives simultaneously. The card supports high-speed data transfer interfaces and is easy to install without the need for driver installation.

• Connects one M.2 port (M key) to a PCI-E x4 interface
• Connects a second M.2 port (B key) to a SATA 6G interface
• Supports two M.2 SSDs at the same time
• Supports PCI-E interface (M key) at up to 32Gbps
• Supports SATA interface (B key) at up to 6Gbps
• No driver installation required

Interface: PCI Express X4 / SATA 6Gbps SSD
Interface: M.2 (NGFF)
Module Key: B key (SATA-based), M key (PCI-E 4X-based, NVMe)
Number of Drives Supported: 2
Supported M.2 SSD Types: 2230, 2242, 2260, 2280
Supported Length of M.2 SSD: 30mm, 42mm, 60mm, 80mm

Note: M key M.2 is for PCI-E (NVMe) SSDs only, B key M.2 is for SATA SSDs only. B key M.2 SSDs require a SATA 7-pin cable connected to the motherboard. NVMe M.2 SSDs require a compatible motherboard with a chipset such as Z97, H97, Z170, or X99, and a Windows 8 or higher operating system. It is recommended to update your motherboard’s driver and BIOS to the latest version before installation.

Package Contents:
– 1x PCI Express Expansion Card
– 2x Mounting Screws
– 1x SATA Cable
